Презентация продукции
| Model | TYB-1300 | TYB-2200 | TYB-2600 | TYB-3000 | TYB-3200 |
| Working Length | 1300mm | 2200mm | 2600mm | 3000mm | 3200mm |
| Ram Cylinder | 2 Groups | 2 Groups | 2 Groups | 2 Groups | 2 Groups |
| Weight | 1700kg | 2800kg | 3200kg | 4800kg | 5000kg |
| Pressing Power | 60kn | 100kn | 110kn | 130kn | 130kn |
| Bending Angle | 0° - 110° | 0° - 110° | 0° - 110° | 0° - 110° | 0° - 110° |
| Opening Height | 120mm | 120mm | 120mm | 120mm | 120mm |
| Workbench Width | 780mm | 780mm | 780mm | 850mm | 850mm |
| Workbench Action Component | Hydraulic Dual Circuit | Hydraulic Dual Circuit | Hydraulic Dual Circuit | Hydraulic Dual Circuit | Hydraulic Dual Circuit |
| Power of Hydraulic Station Motor | 4KW | 5.5KW | 7.5KW | 11KW | 11KW |
| Total Power | 4.5KW | 6KW | 8KW | 12KW | 12KW |
| Overall Dimension | 2200×1200×1650mm | 3100×1250×1650mm | 3500×1250×1650mm | 3900×1400×1650mm | 4100×1400×1650mm |
| Processing Time for Workpiece | 4 Seconds | 6 Seconds | 6 Seconds | 8 Seconds | 8 Seconds |
| Maximum Bending Thickness | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate |
| Maximum Bending Length | 1300mm | 2200mm | 2600mm | 3000mm | 3200mm |
| Maximum Slit Thickness | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate |
| Minimum Folding Size | 6mm | 6mm | 6mm | 7mm | 6mm |
| System | Industrial PC and Rotary Encoder for Controlling Bending Angle | Industrial PC and Rotary Encoder for Controlling Bending Angle | Industrial PC and Rotary Encoder for Controlling Bending Angle | Industrial PC and Rotary Encoder for Controlling Bending Angle | Industrial PC and Rotary Encoder for Controlling Bending Angle |
| CNC Positioning System | Servo System Automatically Controls Bending Length | Servo System Automatically Controls Bending Length | Servo System Automatically Controls Bending Length | Servo System Automatically Controls Bending Length | Servo System Automatically Controls Bending Length |
| Operating Console | The operation display is fixed on the swing arm and has automatic and manual functions | The operation display is fixed on the swing arm and has automatic and manual functions | The operation display is fixed on the swing arm and has automatic and manual functions | The operation display is fixed on the swing arm and has automatic and manual functions | The operation display is fixed on the swing arm and has automatic and manual functions |
| Angle Program | Input from 0° to 110° on the screen | Input from 0° to 110° on the screen | Input from 0° to 110° on the screen | Input from 0° to 110° on the screen | Input from 0° to 110° on the screen |
| Upper Workbench Control | Point Control by Buttons and Pedals on the Control Box | Point Control by Buttons and Pedals on the Control Box | Point Control by Buttons and Pedals on the Control Box | Point Control by Buttons and Pedals on the Control Box | Point Control by Buttons and Pedals on the Control Box |
| Lower Workbench Control | Button Point Control for Manual Control, Pedal Start for Automatic Control | Button Point Control for Manual Control, Pedal Start for Automatic Control | Button Point Control for Manual Control, Pedal Start for Automatic Control | Button Point Control for Manual Control, Pedal Start for Automatic Control | Button Point Control for Manual Control, Pedal Start for Automatic Control |
| Emergency Stop | Manually Press the Emergency Stop Button on the Control Box | Manually Press the Emergency Stop Button on the Control Box | Manually Press the Emergency Stop Button on the Control Box | Manually Press the Emergency Stop Button on the Control Box | Manually Press the Emergency Stop Button on the Control Box |
