Презентация продукции
| Model | TYSK-1300 | TYSK-2200 | TYSK-2600 | TYSK-3200 |
| Working Length | 1300mm | 2200mm | 2600mm | 3200mm |
| Number of Motor Shafts | 6 Axes | 7 Axes | 8 Axes | 8 Axes |
| Weight | 2200kg | 4000kg | 4500kg | 5000kg |
| Pressing Power | 230nm | 372nm | 558nm | 1560nm |
| Bending Angle | 0° - 135° | 0° - 135° | 0° - 135° | 0° - 135° |
| Opening Height | 200mm | 200mm | 200mm | 260mm |
| Workbench Width | 885mm | 885mm | 885mm | 885mm |
| Workbench Action Component | Servo 4 Channels | Servo 4 Channels | Servo 4 Channels | Servo 4 Channels |
| Power of Servo Motor | 9.85KW | 14.75KW | 17.65KW | 32KW |
| Total Power | 10.5KW | 15.5KW | 18.5KW | 33KW |
| Overall Dimension | 3240×1250×1500mm | 4100×1250×1650mm | 4600×1400×1650mm | 5350×1800×1650mm |
| Processing Time for Workpiece | 2 Seconds | 3 Seconds | 3 Seconds | 5 Seconds |
| Maximum Bending Thickness | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate |
| Maximum Bending Length | 1300mm | 2200mm | 2600mm | 3200mm |
| Maximum Slit Thickness | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate | 1.2mm Steel Plate (Yield Strength ≤ 250Mpa), 1.5mm Soft Aluminum Plate |
| Minimum Folding Size | 6mm | 6mm | 6mm | 6mm |
| System | Industrial PC | Industrial PC and Rotary Encoder for Controlling Bending Angle | Industrial PC and Rotary Encoder for Controlling Bending Angle | Industrial PC and Rotary Encoder for Controlling Bending Angle |
| CNC Positioning System | Servo System Automatically Controls Bending Length | Servo System Automatically Controls Bending Length | Servo System Automatically Controls Bending Length | Servo System Automatically Controls Bending Length |
| Operating Console | The operation display is fixed on the swing arm and has automatic and manual functions | The operation display is fixed on the swing arm and has automatic and manual functions | The operation display is fixed on the swing arm and has automatic and manual functions | The operation display is fixed on the swing arm and has automatic and manual functions |
| Angle Program | Input from 0° to 135° on the screen | Input from 0° to 135° on the screen | Input from 0° to 135° on the screen | Input from 0° to 135° on the screen |
| Upper Workbench Control | Point Control by Buttons and Pedals on the Control Box | Point Control by Buttons and Pedals on the Control Box | Point Control by Buttons and Pedals on the Control Box | Point Control by Buttons and Pedals on the Control Box |
| Lower Workbench Control | Button Point Control for Manual Control, Pedal Start for Automatic Control | Button Point Control for Manual Control, Pedal Start for Automatic Control | Button Point Control for Manual Control, Pedal Start for Automatic Control | Button Point Control for Manual Control, Pedal Start for Automatic Control |
| Emergency Stop | Manually Press the Emergency Stop Button on the Control Box | Manually Press the Emergency Stop Button on the Control Box | Manually Press the Emergency Stop Button on the Control Box | Manually Press the Emergency Stop Button on the Control Box |
